Butterfly Check Valve

Automatic opening and closing: automatic control by medium flow, no external operation required, saving labor costs.

Efficient anti-backflow: one-way flow design, rapid closure through fluid pressure and valve disc deadweight, reliably preventing medium backflow.

Compact structure: butterfly valve disc has simple design, small size, convenient installation and maintenance, and is suitable for pipeline systems with limited space.

Reliable sealing: when reverse flow occurs, the valve disc and valve seat are tightly combined, effectively cutting off the flow, and the sealing performance is good.

Wide application: not only used for conventional pipeline one-way control, but also can provide pressure protection for auxiliary systems to prevent overpressure reverse replenishment.

A butterfly check valve is a valve that automatically opens and closes, the valve disc by the flow of the medium itself, and is used to prevent the medium from flowing back. The function of the butterfly check valve is to allow the medium to flow in one direction only and prevent the flow in the other direction. Usually, this valve works automatically.

Under the pressure of the fluid flowing in one direction, the valve disc opens; when the fluid flows in the opposite direction, the fluid pressure and the self-reclosing valve disc act on the valve seat, thereby cutting off the flow. The check valve can also be used on pipelines that provide supply to auxiliary systems where the pressure may rise to exceed

the system pressure.
